| 基本尺寸 | 基本額定載荷 | 軸承類型 | 軸承圖片 | 型號 | |||
|---|---|---|---|---|---|---|---|
| dynamic | static | Type | Images | Model | |||
| d[mm] | D[mm] | B[mm] | C[kN] | C0[kN] | |||
| 240 | 500 | 95 | 1030000 | 1980000 | 角接觸球軸承 |  |
QJ348-N2-MPA |
| 240 | 440 | 72 | 640000 | 1110000 | 角接觸球軸承 | |
QJ248-N2-MPA |
| 220 | 460 | 88 | 900000 | 1650000 | 角接觸球軸承 | |
QJ344-N2-MPA |
| 220 | 400 | 65 | 630000 | 1120000 | 角接觸球軸承 | |
QJ244-N2-MPA |
| 200 | 360 | 58 | 510000 | 850000 | 角接觸球軸承 | |
QJ240-N2-MPA |
| 200 | 310 | 51 | 390000 | 620000 | 角接觸球軸承 | |
QJ1040-N2-MPA |
| 190 | 400 | 78 | 740000 | 1250000 | 角接觸球軸承 | |
QJ338-N2-MPA |
| 190 | 340 | 55 | 460000 | 740000 | 角接觸球軸承 | |
QJ238-N2-MPA |
| 190 | 290 | 46 | 345000 | 540000 | 角接觸球軸承 | |
QJ1038-N2-MPA |
| 180 | 380 | 75 | 690000 | 1130000 | 角接觸球軸承 | |
QJ336-N2-MPA |
| 180 | 320 | 52 | 435000 | 680000 | 角接觸球軸承 | |
QJ236-N2-MPA |
| 180 | 280 | 46 | 340000 | 510000 | 角接觸球軸承 | |
QJ1036-N2-MPA |
| 170 | 360 | 72 | 590000 | 920000 | 角接觸球軸承 | |
QJ334-N2-MPA |
| 170 | 310 | 52 | 420000 | 630000 | 角接觸球軸承 | |
QJ234-N2-MPA |
| 170 | 260 | 42 | 280000 | 430000 | 角接觸球軸承 | |
QJ1034-N2-MPA |
| 160 | 340 | 68 | 580000 | 870000 | 角接觸球軸承 | |
QJ332-N2-MPA |
| 160 | 290 | 48 | 370000 | 530000 | 角接觸球軸承 | |
QJ232-N2-MPA |
| 160 | 240 | 38 | 231000 | 335000 | 角接觸球軸承 | |
QJ1032-N2-MPA |
| 150 | 320 | 65 | 510000 | 730000 | 角接觸球軸承 | |
QJ330-N2-MPA |
| 150 | 270 | 45 | 350000 | 485000 | 角接觸球軸承 | |
QJ230-N2-MPA |
| 150 | 225 | 35 | 205000 | 295000 | 角接觸球軸承 | |
QJ1030-N2-MPA |
| 140 | 300 | 62 | 470000 | 660000 | 角接觸球軸承 | |
QJ328-N2-MPA |
| 140 | 250 | 42 | 315000 | 420000 | 角接觸球軸承 | |
QJ228-N2-MPA |
| 130 | 280 | 58 | 425000 | 570000 | 角接觸球軸承 | |
QJ326-N2-MPA |
| 130 | 230 | 40 | 295000 | 370000 | 角接觸球軸承 | |
QJ226-N2-MPA |
| 120 | 260 | 55 | 385000 | 485000 | 角接觸球軸承 | |
QJ324-N2-MPA |
| 120 | 215 | 40 | 285000 | 340000 | 角接觸球軸承 | |
QJ224-N2-MPA |
| 120 | 180 | 28 | 145000 | 200000 | 角接觸球軸承 | |
QJ1024-N2-MPA |
| 110 | 240 | 50 | 345000 | 415000 | 角接觸球軸承 | |
QJ322-N2-MPA |
| 110 | 200 | 38 | 249000 | 285000 | 角接觸球軸承 | |
QJ222-N2-MPA |
